SDF-5.0-100 | Talema
Storage choke, PCB mounting, 100 µH, 5 A, SDF-5.0-100
NCNR (non cancelable / non returnable)
Unit Price (€ / pc.)
11.8762 € *
Available: 8 pcs.
Total Price:
11.88 € *
Price list
Quantity
Price per unit*
1 pcs.
11.8762 €
5 pcs.
11.2812 €
10 pcs.
10.6981 €
50 pcs.
10.1745 €
100 pcs.
9.6985 €
*incl. VAT plus shipping costs
Subject to prior sale
Linear smoothing chokes, type Talema SD 0,63/500.
In molded housing, horizontal, for PCB connection, metal-powder core
Size 29.5 x 29 x 13.5 mm, type SD.
Technical specifications
| Filter | Property | Value |
|---|---|---|
| Version | storage choke | |
| Inductance | 100 µH | |
| DC current | 5 A | |
| DC resistance | 27 mΩ | |
| Measuring frequency | 200 kHz | |
| Design | PCB mounting | |
| Length | 29.5 mm | |
| Width | 29 mm | |
| Height | 13.5 mm |
Download
Logistics
| Property | Value |
|---|---|
| Country of origin | IN |
| Customs tariff number | 85045000 |
Compliance
| Property | Value |
|---|---|
| RoHS conform | Yes |
| Date of RoHS guidelines | 3/31/15 |
| SVHC free | Yes |
