BAT46 | STMicroelectronics
Schottky rectifier diode, 100 V (RRM), 0.15 A, SOT-23, BAT46
No longer available from manufacturer
Unit Price (€ / pc.)
0.0417 € *
Available: 10 pcs.
Available in 5 Days: 24,600 pcs. - if ordered today
Total Price:
0.04 € *
Price list
Quantity
Price per unit*
1 pcs.
0.0417 €
25 pcs.
0.0381 €
100 pcs.
0.0346 €
250 pcs.
0.0320 €
*incl. VAT plus shipping costs
Subject to prior sale
Schottky diode, BAT46, STMicroelectronics
High voltage small signal Schottky diode suited for protection and routing operations.
Features
- Very small conduction losses
- Negligible switching losses
- Low forward and reverse recovery times
- Extremely fast switching
- Low capacitance diode
Applications
- General rectification
- Reverse polarity protection
- Voltage clamping
- High-speed switching
Technical specifications
| Filter | Property | Value |
|---|---|---|
| Product type | schottky rectifier diode | |
| Enclosure | SOT-23 | |
| Voltage V RRM (peak reverse voltage) | 100 V | |
| Forward Current | 0.15 A | |
| Number of diodes | 1 | |
| Junction temperature (max.) | 150 °C | |
| Capacity | 10 pF | |
| Assembly | SMD | |
| min. operating temperature | -65 °C | |
| max. operating temperature | 150 °C |
Download
Logistics
| Property | Value |
|---|---|
| Original Packaging | Reel with 4,000 pieces |
| Country of origin | CN |
| Customs tariff number | 85411000 |
| MSL | MSL 1 |
Compliance
| Property | Value |
|---|---|
| Substance description | Lead |
| RoHS conform | Yes |
| Date of RoHS guidelines | 3/31/15 |
| SVHC free | No |
