L6235PD013TR | STMicroelectronics

IC, SO36, 7 V, 52 V

Order No.: 41S1096
EAN: 4099879102058
MPN:
L6235PD013TR
L6235PD013TR STMicroelectronics Motor Control ICs
Image may differ
Unit Price (€ / pc.)
7.8540 € *
Standard delivery time from the manufacturer is: On Request
Total Price:
4,712.40 € *
*incl. VAT plus shipping costs
Subject to prior sale
600 pcs.
7.8540 €

IC, L6235PD, STMicroelectronics

The L6235PD device is a DMOS fully integrated 3-phase motor driver with overcurrent protection. Realized in BCDtechnology, the device combines isolated DMOS power transistors with CMOS and bipolar circuits on the same chip. The device includes all the circuitry needed to drive a 3-phase BLDC motor including: a 3-phase DMOS bridge, a constant off time PWM current controller and the decoding logic for single ended hall sensors that generates the required sequence for the power stage.

Features

  • Cross conduction protection
  • Tachometer output for speed loop
  • Brake function
  • Diagnostic output
Technical specifications
Assembly SMD
Enclosure SO-36
Output current 2.8 A
min. operating temperature -40 °C
max. operating temperature 150 °C
Logistics
Country of origin MY
Customs tariff number 85423390
MSL MSL 3
Original Packaging Reel with 600 pieces
Compliance
Date of RoHS guidelines 3/31/15
SVHC free Yes
RoHS conform Yes
