L6201 | STMicroelectronics
IC, SO20, 12 V, 48 V
Order No.: 41S1183
EAN: 4099879102065
MPN:
L6201
NCNR (non cancelable / non returnable)
Unit Price (€ / pc.)
8.2110 € *
Available in 5 Days: 400 pcs. - if ordered today
Total Price:
41.06 € *
Price list
Quantity
Price per unit*
5 pcs.
8.2110 €
25 pcs.
7.6755 €
100 pcs.
7.2590 €
*incl. VAT plus shipping costs
Subject to prior sale
IC, L6201, STMicroelectronics
The IC is a full bridge driver for motor control applications realized in Multipower-BCD technology which combines isolated DMOS power transistors with CMOS and Bipolar circuits on the same chip. By using mixed technology it has been possible to optimize the logic circuitry and the power stage to achieve the best possible performance. The DMOS output transistors can operate at supply voltages up to 42 V and efficiently at high switching speeds.
All the logic inputs are TTL, CMOS and µC compatible. Each channel (half-bridge) of the device is controlled by a separate logic input, while a common enable controls both channels.
Features
- High efficiency
- Thermal shutdown
Technical specifications
| Filter | Property | Value |
|---|---|---|
| Enclosure | SOIC-20 | |
| Assembly | THT | |
| Output current | 1 A | |
| min. operating temperature | -40 °C | |
| max. operating temperature | 150 °C |
Download
Logistics
| Property | Value |
|---|---|
| Customs tariff number | 85423390 |
| MSL | MSL 3 |
| Country of origin | MY |
Compliance
| Property | Value |
|---|---|
| SVHC free | Yes |
| Date of RoHS guidelines | 3/31/15 |
| RoHS conform | Yes |
