STM32F103C8T6 | STMicroelectronics
ARM Cortex M4 microcontroller, 32 bit, 72 MHz, LQFP-48, STM32F103C8T6
Unit Price (€ / pc.)
1.7017 € *
Available in 5 Days: 11,416 pcs. - if ordered today
Total Price:
1.70 € *
Price list
Quantity
Price per unit*
1 pcs.
1.7017 €
25 pcs.
1.5827 €
100 pcs.
1.4756 €
250 pcs.
1.4161 €
*incl. VAT plus shipping costs
Subject to prior sale
ARM Cortex M4 microcontroller, STM32F103C8T6, STMicroelectronics
The STM32F103C8T6 y incorporates the highperformance ARM Cortex-M3 32-bit RISC core operating at a 72 MHz frequency, highspeed embedded memories (Flash memory up to 128 Kbytes and SRAM up to 20 Kbytes),and an extensive range of enhanced I/Os and peripherals connected to two APB buses.
Applications
- Motor drive and application control
- Medical and handheld equipment
- PC peripherals gaming and GPS platforms
- Industrial applications: PLC, inverters, printers, and scanners
- Alarm systems, video intercom, and HVAC
Technical specifications
| Filter | Property | Value |
|---|---|---|
| Core Size | 32 bit | |
| Data RAM Size | 20 KB | |
| Memory size | 64 KB | |
| Assembly | SMD | |
| Number of pins | 48 | |
| Enclosure | LQFP-48 | |
| Number of I/Os | 48 | |
| Clock frequency | 72 MHz | |
| max. operating temperature | 85 °C | |
| Processor core | ARM Cortex M4 | |
| min. operating temperature | -40 °C | |
| Version | flash | |
| Voltage | 2-3.6 V |
Download
Logistics
| Property | Value |
|---|---|
| Country of origin | MY |
| MSL | MSL 2 |
| Original Packaging | Tray with 250 pieces |
| Customs tariff number | 85423190 |
Compliance
| Property | Value |
|---|---|
| Date of RoHS guidelines | 3/31/15 |
| RoHS conform | Yes |
| SVHC free | Yes |
