BD438 | STMicroelectronics
Bipolar junction transistor, PNP, -4 A, -45 V, THT, TO-126, BD438
Unit Price (€ / pc.)
0.6307 € *
Available: 85 pcs.
Available in 5 Days: 1,050 pcs. - if ordered today
Total Price:
0.63 € *
Price list
Quantity
Price per unit*
1 pcs.
0.6307 €
25 pcs.
0.4165 €
100 pcs.
0.3808 €
250 pcs.
0.3213 €
1000 pcs.
0.2796 €
*incl. VAT plus shipping costs
Subject to prior sale
Transistors series BD.
Technical attributes (type, package, manufacturer): BD438, TO126
Technical specifications
| Filter | Property | Value |
|---|---|---|
| Version | PNP | |
| Assembly | THT | |
| Enclosure | TO-126 | |
| Rated current | 4 A | |
| Collector current | -4 A | |
| min. operating temperature | -65 °C | |
| Power dissipation | 36 W | |
| Transit frequency fTmin | 3 MHz | |
| Saturation voltage | -600 mV | |
| max. operating temperature | 150 °C | |
| max.voltage between collector and base Vcbo | -45 V | |
| max.voltage between collector and emitter Vceo | -45 V |
Download
Logistics
| Property | Value |
|---|---|
| Customs tariff number | 85412900 |
| Country of origin | CN |
| Original Packaging | Bar with 50 pieces |
Compliance
| Property | Value |
|---|---|
| RoHS conform | Yes |
| SVHC free | Yes |
| Date of RoHS guidelines | 3/31/15 |
