02520.1-04 | STEGO

LED switch cabinet light, 9 W, 230 V, 510 lm, 02520.1-04

Order No.: 80H7947
EAN: 4251823458042
MPN:
02520.1-04
Series: SL 025
02520.1-04 STEGO Luminaires and Light Fixtures
Image may differ
Unit Price (€ / pc.)
179.4758 € *
Standard delivery time from the manufacturer is: 2 Weeks
Total Price:
179.48 € *
*incl. VAT plus shipping costs
Subject to prior sale
1 pcs.
179.4758 €

Control cabinet light, 02520.1-04, STEGO

The flat slimline luminaire 02520.1-04 with motion detector is ideally suited for use in cabinets and enclosures with electrical/electronic fixtures with high component density. The luminaire can be mounted in any desired position in steel cabinets without any mounting effort.

Features

  • Slim casing
  • Electronic ballast
  • Energy saving lamp
  • Automatic switching
  • With magnetic holder
  • With socket
Technical specifications
Filter Property Value
Luminous flux 510 lm
Width 40 mm
Version light with magnet, motion switch and socket
Degree of protection (IP) IP20
max. operating temperature 70 °C
average nominal life 10000 h
Length 345 mm
Height 91 mm
Power 9 W
min. operating temperature -45 °C
Colour gray
Rated voltage 230 V
Logistics
Property Value
Customs tariff number 94054940
Country of origin DE
Compliance
Property Value
Date of RoHS guidelines 3/31/15
RoHS conform Yes
SVHC free Yes
