MK14-1A84B-500W | Standex Electronics

Reed switche, built-in mounting, 1 Form A (N/O), 10 W, 400 V (DC), 0.5 A, MK14-1A84B-500W

Order No.: 30G264
EAN: 4099889448771
MPN:
MK14-1A84B-500W
9142841054
Series: MK14
MK14-1A84B-500W Standex Electronics Proximity Switches, Reed switches Image 1
MK14-1A84B-500W Standex Electronics Proximity Switches, Reed switches Image 2
Image may differ
Unit Price (€ / pc.)
12.1380 € *
Standard delivery time from the manufacturer is: 5 Weeks
Total Price:
1,213.80 € *
Price list
Quantity
Price per unit*
100 pcs.
12.1380 €
150 pcs.
11.4835 €
*incl. VAT plus shipping costs
Subject to prior sale

Reed sensor, MK14-1A84B-500W, Standex Electronics

The MK14-1A84B-500W is a panel mount (4.0mm) reed sensor are supplied in a cylindrically shaped housing with cable terminals. Optional internal switch, cable, length, and termination. UL Approval.

Applications

  • Door and window contacts
  • With magnetic floats for water level detection
  • Position sensing
  • Appliance
  • Industrial
  • Security
Technical specifications
Filter Property Value
diameter 4 mm
switching current 0.5 A
Switching Voltage (DC) 400 V
Assembly built-in mounting
Latching switching function 1 Form A (N/O)
Breaking capacity 10 W
Product type reed sensor
Contact resistance 150 mΩ
Connection stranded wires
Length 25.5 mm
Logistics
Property Value
Country of origin DE
Customs tariff number 85365080
Compliance
Property Value
Date of RoHS guidelines 3/31/15
RoHS conform Yes
SVHC free Yes
