66.9426-15023 | Stäubli Electrical Connectors
Measuring lead with (test probe, straight) to (4 mm plug, spring-loaded, straight), 1.5 m, blue, TPE, 0.5 mm², 66.9426-15023
Order No.: 86F6974
EAN: 4099891078416
MPN:
66.9426-15023
XHL-5000 BLAU
This item is no longer available.
As an alternative, we recommend the following item:
Safety measuring lead with (test probe, straight) to (4 mm lamella plug, straight), 1.5 m, blue, TPE, 0.5 mm², CAT IV, 66.8011-15023
Order No.: 86F0947
Manufacturer: Stäubli Electrical Connectors
per pc. 14.8274 € *
Measuring lead, 66.9426-15023, Stäubli Electrical Connectors
Highly flexible. One end with Ø 4 mm test probe with spring-loaded MULTILAM, the other end with in-line Ø 4 mm MULTILAM plug with rigid insulating sleeve. Supplied with protective cap.
Technical specifications
| Cable length | 1.5 m | |
| Colour | blue | |
| contact surface | nickel-plated | |
| Cable cross-section | 0.5 mm² | |
| Stackable | No | |
| Connection (2) | 4 mm plug, spring-loaded, straight | |
| Touch safe | Yes | |
| Material | TPE | |
| Rated Voltage | 5000 V | |
| Connection (1) | test probe, straight | |
| Rated current | 10 A |
Download
Logistics
| Country of origin | DE |
| Customs tariff number | 85446090 |
Compliance
| Date of RoHS guidelines | 3/31/15 |
| Substance description | Lead |
| SVHC free | No |
| RoHS conform | Yes |
