66.9515-21 | Stäubli Electrical Connectors
Magnetic adapter, 11 mm magnetic head to 4 mm socket, black, CAT IV, 66.9515-21
Unit Price (€ / pc.)
21.8246 € *
Available: 9 pcs.
Total Price:
21.82 € *
Price list
Quantity
Price per unit*
1 pcs.
21.8246 €
5 pcs.
19.9682 €
10 pcs.
18.7187 €
50 pcs.
17.4692 €
100 pcs.
16.2078 €
*incl. VAT plus shipping costs
Subject to prior sale
Magnetic adapter, 66.9515-21, Stäubli Electrical Connectors
Made of brass for permanent installation, for example, for connecting screw terminals. Ø 4 mm rigid socket in insulator accepting spring-loaded Ø 4 mm plugs with rigid insulating sleeve. Fork lug bent to an angle of 45°. Color: black.
Technical specifications
| Filter | Property | Value |
|---|---|---|
| Site (2) | 4 mm socket | |
| contact surface | nickel-plated | |
| Rated Voltage | 1000 V | |
| Site (1) | 11 mm magnetic head | |
| Rated category | CAT IV | |
| Rated current | 2 A | |
| Colour | black | |
| Version | magnetic adapter |
Download
Logistics
| Property | Value |
|---|---|
| Country of origin | DE |
| Customs tariff number | 85369010 |
Compliance
| Property | Value |
|---|---|
| Date of RoHS guidelines | 3/31/15 |
| Substance description | Lead |
| RoHS conform | Yes |
| SVHC free | No |
