32.0022P0001-UR | Stäubli Electrical Connectors

MC4-Evo 2 surface mount socket, 4.0-6.0 mm², 1.5 kV, 42 A, 32.0022P0001-UR

Order No.: 37F418

EAN: 4099889883503

MPN:

32.0022P0001-UR

PV-ADB4-EVO 2/6-UR

Image may differ

Key Specification:

Version MC4-Evo 2 surface mount socket

diameter 4 mm

Cable cross-section 4.0-6.0 mm²

Rated voltage 1.5 kV

Download Datasheet Technical specifications

This item is no longer available.

As an alternative, we recommend the following item:

MC4-Evo 2 surface mount socket, 4.0-6.0 mm², 1.5 kV, 42 A, 32.0346P0001

Order No.: 37F2048

Manufacturer: Stäubli Electrical Connectors

per pc. 4.5339 € *

Go to product

*incl. VAT plus shipping costs

Description

Female receptacle, 32.0022P0001-UR, Stäubli Electrical Connectors

MC4-Evo 2 panel-receptacle connector is the interface between the inverter or the distributor housing and string. Assembly directly via the threads or in the perforated plate with the plastic nut. Thanks to the D shape, the threaded connection is secured against turning. This degree of protection (IP68) guarantees highest connection safety, fast and clean connection with preassembled flat seal. Plug compatible with the original MC4 plug connector family.

Technical specifications

Filter	Property	Value
	Contact connection	crimp terminal open
	Rated current	42 A
	Version	MC4-Evo 2 surface mount socket
	diameter	4 mm
	Rated voltage	1.5 kV
	Cable cross-section	4.0-6.0 mm²
