23.3140-28 | Stäubli Electrical Connectors
4 mm socket, threaded bolt, mounting Ø 12.2 mm, CAT III, gray, 23.3140-28
Unit Price (€ / pc.)
3.1297 € *
Next delivery: 17 pcs. on 2025-07-11
Total Price:
3.13 € *
Price list
Quantity
Price per unit*
1 pcs.
3.1297 €
20 pcs.
2.7489 €
100 pcs.
2.5704 €
500 pcs.
2.4633 €
1000 pcs.
2.3324 €
*incl. VAT plus shipping costs
Subject to prior sale
4 mm Socket, 23.3140-28, Stäubli Electrical Connectors
Insulated, Ø 4 mm rigid sockets accepting spring-loaded Ø 4 mm plugs with rigid insulating sleeve. Machined brass. The socket is pressed into predrilled panels of plastic, metal etc. Connection: Threaded bolt M4 and soldering hole.
Technical specifications
| Rated Voltage | 1000 V | |
| Rated current | 32 A | |
| Version | press-in socket | |
| Connection | threaded bolt | |
| Installation diameter | 12.2 mm | |
| Touch safe | Yes | |
| Rated category | CAT III | |
| Colour | gray | |
| Length | 38.5 mm | |
| contact surface | gold-plated | |
| Stackable | No | |
| diameter | 4 mm |
Download
Logistics
| Country of origin | CH |
| Customs tariff number | 85369010 |
| Original Packaging | Bag with 20 pieces |
Compliance
| RoHS conform | Yes |
| Substance description | Lead |
| Date of RoHS guidelines | 3/31/15 |
| SVHC free | No |
