3NA3805 | Siemens
NH fuse NH000, 16 A, gG, 250 V (DC), 500 V (AC), 3NA3805
Order No.: 27H2240
EAN: 4001869056883
MPN:
3NA3805
Unit Price (€ / pc.)
4.0460 € *
Standard delivery time from the manufacturer is: 1 Week
Total Price:
4.05 € *
Price list
Quantity
Price per unit*
1 pcs.
4.0460 €
3 pcs.
3.8675 €
6 pcs.
3.6890 €
15 pcs.
3.4867 €
30 pcs.
3.3082 €
*incl. VAT plus shipping costs
Subject to prior sale
LV HRC fuse element, NH000, In: 16 A, gG, Un AC: 500 V, Un DC: 250 V, Front indicator, live grip lugs.
Technical specifications
| Filter | Property | Value |
|---|---|---|
| Tripping characteristics | gG | |
| Width | 21 mm | |
| Rated voltage (AC) | 500 V | |
| Enclosure | ceramic tube | |
| Rated voltage (DC) | 250 V | |
| Length | 52.5 mm | |
| Design | NH000 | |
| Version | NH fuse | |
| Height | 77.8 mm | |
| Rated current | 16 A |
Download
Logistics
| Property | Value |
|---|---|
| Country of origin | GR |
| Customs tariff number | 85361050 |
Compliance
| Property | Value |
|---|---|
| RoHS conform | Yes |
| SVHC free | Yes |
| Date of RoHS guidelines | 3/31/15 |
