6ES7222-1BD30-0XB0 | Siemens
SIMATIC S7-1200 digital output module, 6ES7222-1BD30-0XB0
Order No.: 70P4776
EAN: 6940408100794
MPN:
6ES7222-1BD30-0XB0
6ES72221BD300XB0
Series: SIMATIC S7-1200
Unit Price (€ / pc.)
93.0342 € *
Standard delivery time from the manufacturer is: 1 Week
6ES72221BD300XB0, Siemens
SIMATIC S7-1200, Digital output SB 1222, 4 DQ, 24 V DC 200 kHz SIMATIC S7-1200 Basic Controller - Flexible thanks to wide variety of communication options If you only have to extend your SIMATIC S7-1200 CPU with a few inputs or outputs, signal boards are a good alternative to signal modules. Signal boards are plugged directly onto the front of the controller (also possible with the CPU 1211C) and are available as digital and analog input, output and hybrid modules. A communications board with an RS 485 interface is also available. Signal boards thus permit subsequent expansion of the configuration without requiring any further space in the control cabinet.
Technical specifications
| Depth | 21 mm | |
| Assembly | DIN rail | |
| Width | 38 mm | |
| Height | 62 mm | |
| Version | digital output module (DO 4x24 VDC 200 kHz) |
Download
Logistics
| Country of origin | CN |
| Customs tariff number | 85389091 |
Compliance
| Date of RoHS guidelines | 3/31/15 |
| Substance description | Lead, lead monoxide (lead oxide) |
| SVHC free | No |
| RoHS conform | Yes |
