3VA5290-6ED31-2AA0 | Siemens

Name: Circuit breaker, 3 pole, H Curve, 90 A, DIN rail
Brand: Siemens
SKU: 81P4796
Price: 771.98 EUR
Availability: OutOfStock

Circuit breaker, 3 pole, H Curve, 90 A, DIN rail

Order No.: 81P4796

EAN: 4047624205752

MPN:

3VA5290-6ED31-2AA0

3VA52906ED312AA0

Series: 3VA5

Image may differ

Key Specification:

Pin number 3 pole

Tripping characteristics H

Rated current 90 A

Show 565 variants

Download Datasheet Technical specifications

Unit Price (€ / pc.)

771.9768 € *

Available: 0 pcs.

Leadtime: 2 Weeks **

Add to Cart

Total Price:

771.98 € *

*incl. VAT plus shipping costs

**Subject to prior sale

Description

Circuit breaker 3VA5 UL frame 250 Breaking capacity Class H 65kA @ 480 V 3-pole, line protection TM210,FTFM, In=90A without overload protection Ir=90A Fixed Short circuit protection Ii=10 x In W/O connection.

Technical specifications

	Tripping characteristics	H
	Rated current	90 A
	Assembly	DIN rail
	Pin number	3 pole

Show similar products 0

Download

Declaration of Conformity - EN Declaration of Conformity

Technical Data Sheet - DE Technical Data Sheet

Declaration of Conformity - DE Declaration of Conformity

Logistics

Country of origin	CZ
Customs tariff number	85362090

Compliance

RoHS conform	Yes
Date of RoHS guidelines	3/31/15
SVHC free	Yes
