3SB2000-2EC01 | Siemens

Toggle switch, unlit, groping, waistband round, red, front ring black, 2 x 50°, trigger position 1 + 0 + 2, mounting Ø 16 mm, 3SB2000-2EC01

Order No.: 80P7202
EAN: 4011209027787
MPN:
3SB2000-2EC01
3SB20002EC01
3SB2000-2EC01 Siemens Actuators, Signal Elements and Front Elements
Image may differ
Unit Price (€ / pc.)
23.5977 € *
Standard delivery time from the manufacturer is: 2 Weeks
Total Price:
23.60 € *
*incl. VAT plus shipping costs
Subject to prior sale
1 pcs.
23.5977 €
Selector switch, 16 mm, round, plastic, red, 3 switch positions IOII, momentary contact type, Retraction from left and right, Actuating angle 2 x 50 degree Selector switches SIRIUS 3SB2 for switching and controlling electrical loads.
Technical specifications
Filter Property Value
Trigger position key 1 + 0 + 2
Protection class IP65
Installation depth 50 mm
Contact function groping
Installation height 17 mm
Installation diameter 16 mm
Type of mounting front panel mounting
Rotation angle 2 x 50°
Collar shape of the front frame round
Actuator colour red
Front ring colour black
can be illuminated No
Product type toggle switch
Logistics
Property Value
Customs tariff number 85389099
Country of origin CZ
Compliance
Property Value
RoHS conform Yes
SVHC free Yes
Date of RoHS guidelines 3/31/15
