0603 0120 010 | SES-Sterling
Heatshrink tubing, 2:1, (25.4/12.7 mm), PO, crosslinked, black, 0603 0120 010
Unit Price (€ / mtr.)
6.3546 € *
Available in 7 Days: 25 mtr. - if ordered today
Total Price:
317.73 € *
Price list
Quantity
Price per unit*
50 mtr.
6.3546 €
150 mtr.
5.9381 €
*incl. VAT plus shipping costs
Subject to prior sale
Heat shrink tubing, 0603 0120 010, SES-Sterling
Heat shrinkable tubing PLIOFINE is composed of cross-linked Polyolefin (derived from polyethylene), unlike heat shrinkable sleeving PLIO "R" it cannot be melted or welded and has excellent chemical properties. It is cost effective. Dielectric properties, ageing and weather resistance are excellent, and the sleeving needs no special storing conditions as it remains inert up to +50°C.
Technical specifications
| Filter | Property | Value |
|---|---|---|
| Shrinking rate | 2:1 | |
| contains glue inside | No | |
| min. operating temperature | -55 °C | |
| max. operating temperature | 125 °C | |
| Inner diameter after shrinkage | 12.7 mm | |
| Wall thickness | 0.89 mm | |
| Inner diameter before shrinkage | 25.4 mm | |
| Shrinking temperature | 120 °C | |
| Length | 50 m | |
| Colour | black | |
| Material | PO, crosslinked |
Download
Logistics
| Property | Value |
|---|---|
| Original Packaging | Reel with 50 meters |
| Customs tariff number | 39173200 |
| Country of origin | FR |
Compliance
| Property | Value |
|---|---|
| Date of RoHS guidelines | 3/31/15 |
| RoHS conform | Yes |
| SVHC free | Yes |
