MFB50E12 | SEPA
DC axial fan, 12 V, 50 x 50 x 10 mm, 14.3 m³/h, 26 dB, ball bearing, SEPA MFB50E12
Unit Price (€ / pc.)
14.4585 € *
Available: 23 pcs.
Total Price:
14.46 € *
Price list
Quantity
Price per unit*
1 pcs.
14.4585 €
10 pcs.
13.4708 €
50 pcs.
12.6140 €
100 pcs.
11.8643 €
*incl. VAT plus shipping costs
Subject to prior sale
DC Axial fan, MFB50E12, SEPA
The MFB50E12 is a high-tech mini fan used for industrial and automotive purposes and has a remarkable conveying capacity despite its small dimensions.
Features
- High-capacity standard fan
- High resistance to shock and vibration
- Integrated polarity reversal and anti-blocking protection
- Maximum reliability thanks to 100% burn-in
Technical specifications
| Filter | Property | Value |
|---|---|---|
| Rated voltage | 12 V | |
| speed | 4800 1/min | |
| Width | 50 mm | |
| Volume flow | 14.3 m³/h | |
| Sound pressure level | 26 db | |
| Version | DC axial fan | |
| Height | 50 mm | |
| Depth | 10 mm | |
| Type of bearing | ball bearing |
Download
Logistics
| Property | Value |
|---|---|
| Country of origin | CN |
| Customs tariff number | 84145925 |
Compliance
| Property | Value |
|---|---|
| Date of RoHS guidelines | 3/31/15 |
| SVHC free | Yes |
| RoHS conform | Yes |
