MF20C05L | SEPA
DC axial fan, 5 V, 20 x 20 x 8 mm, 1.3 m³/h, 11 dB, slide bearing, SEPA MF20C05L
Unit Price (€ / pc.)
13.7445 € *
Available: 10 pcs.
Total Price:
13.74 € *
Price list
Quantity
Price per unit*
1 pcs.
13.7445 €
10 pcs.
12.8044 €
50 pcs.
11.9952 €
100 pcs.
11.2812 €
*incl. VAT plus shipping costs
Subject to prior sale
DC Axial fan, MF20C05L, SEPA
The MF20C05L is a high-tech miniature fan that is suitable for industrial or automotive use and has exceptional airflow performance despite its low height of only 6.5 mm.
Features
- It is permanently protected electrically against reverse polarity blocking and thermal overloading
- Suitable for battery-powered devices
- High resistance to shock and vibration
- Maximum reliability thanks to 100% burn-in
Technical specifications
| Filter | Property | Value |
|---|---|---|
| Version | DC axial fan | |
| Rated voltage | 5 V | |
| Width | 20 mm | |
| Height | 20 mm | |
| Depth | 8 mm | |
| Volume flow | 1.3 m³/h | |
| Sound pressure level | 11 db | |
| speed | 7700 1/min | |
| Type of bearing | slide bearing | |
| Power consumption | 0.4 W |
Download
Logistics
| Property | Value |
|---|---|
| Customs tariff number | 84145925 |
| Country of origin | CN |
Compliance
| Property | Value |
|---|---|
| RoHS conform | Yes |
| SVHC free | Yes |
| Date of RoHS guidelines | 3/31/15 |
