3404.2409.11 | SCHURTER
SMD fuse 4.2 x 11.1 mm, 200 mA, T, 250 V (DC), 125 V (AC), 200 A breaking capacity, 3404.2409.11
Unit Price (€ / pc.)
1.0948 € *
Available: 290 pcs.
Total Price:
1.09 € *
Price list
Quantity
Price per unit*
1 pcs.
1.0948 €
10 pcs.
0.9996 €
50 pcs.
0.9044 €
100 pcs.
0.8211 €
*incl. VAT plus shipping costs
Subject to prior sale
SMD-Fuse, 3404.2409.11, SCHURTER
The 3404.2409.11 is a SMT time-lag fuse with clips, and it is used for overcurrent protection applications.
Features
- Material glass tube
- Material terminals copper alloy tin-plated
- Suitable for reflow soldering
- High breaking capacity of 200 A
Applications
- Primary protection on SMD PCB-s
Technical specifications
| Filter | Property | Value |
|---|---|---|
| Rated voltage (DC) | 250 V | |
| Rated voltage (AC) | 125 V | |
| Length | 11.3 mm | |
| Height | 4 mm | |
| Tripping characteristics | T | |
| Width | 4.2 mm | |
| Breaking capacity | 200 A | |
| Design | 4.2 x 11.1 mm | |
| Enclosure | SMD | |
| Version | SMD fuse | |
| Rated current | 200 mA |
Download
Logistics
| Property | Value |
|---|---|
| Country of origin | CH |
| Original Packaging | Blister with 100 pieces |
| Customs tariff number | 85363010 |
Compliance
| Property | Value |
|---|---|
| Date of RoHS guidelines | 3/31/15 |
| RoHS conform | Yes |
| SVHC free | Yes |
