3404.0111.11 | SCHURTER

SMD fuse 7.4 x 3.1 mm, 375 mA, T, 125 V (DC), 125 V (AC), 100 A breaking capacity, 3404.0111.11

Order No.: 59P4920
EAN: 4099889109702
MPN:
3404.0111.11
Series: OMT 125
3404.0111.11 SCHURTER Micro Fuses
Image may differ
Unit Price (€ / pc.)
0.4046 € *
Standard delivery time from the manufacturer is: 6 Weeks
Total Price:
0.40 € *
*incl. VAT plus shipping costs
Subject to prior sale
1 pcs.
0.4046 €

SMD-Fuse, 3404.0111.11, SCHURTER

The 3404.0111.11 is a suitable for capacitive circuits that need power surges upon power input/output or on/off.

Features

  • Material housing thermoplastic
  • Material terminals copper alloy, tin-plated
  • Suitable for reflow and wave soldering
  • Vibration resistant

Applications

  • Primary protection on motor circuits
Technical specifications
Design 7.4 x 3.1 mm
Version SMD fuse
Enclosure SMD
Rated current 375 mA
Tripping characteristics T
Rated voltage (DC) 125 V
Height 2.6 mm
Length 7.4 mm
Rated voltage (AC) 125 V
Breaking capacity 100 A
Width 3.1 mm
Logistics
Original Packaging Reel with 100 pieces
Customs tariff number 85361010
Country of origin CH
MSL MSL 1
Compliance
SVHC free Yes
Date of RoHS guidelines 3/31/15
RoHS conform Yes
