3404.0015.22 | SCHURTER
SMD fuse 7.4 x 3.1 mm, 3.5 A, F, 125 V (DC), 125 V (AC), 100 A breaking capacity, 3404.0015.22
Unit Price (€ / pc.)
0.8211 € *
Standard delivery time from the manufacturer is: 8 Weeks
Total Price:
0.82 € *
Price list
Quantity
Price per unit*
1 pcs.
0.8211 €
10 pcs.
0.7378 €
50 pcs.
0.6664 €
100 pcs.
0.5831 €
*incl. VAT plus shipping costs
Subject to prior sale
SMD-Fuse, 3404.0015.22, SCHURTER
The 3404.0015.22 is a quick-acting fuse that is designed to protect less sensitive components and are also is used to protect cabling from melting or catching fire when an overload occurs.
Features
- Material housing thermoplastic
- Material terminals copper alloy, tin-plated
- Suitable for reflow and wave soldering
- Vibration resistant
Applications
- Primary protection on SMD PCB-s
Technical specifications
| Filter | Property | Value |
|---|---|---|
| Rated voltage (DC) | 125 V | |
| Rated voltage (AC) | 125 V | |
| Length | 7.4 mm | |
| Height | 2.6 mm | |
| Tripping characteristics | F | |
| Width | 3.1 mm | |
| Breaking capacity | 100 A | |
| Design | 7.4 x 3.1 mm | |
| Enclosure | SMD | |
| Version | SMD fuse | |
| Rated current | 3.5 A |
Download
Logistics
| Property | Value |
|---|---|
| Country of origin | CH |
| Original Packaging | Reel with 750 pieces |
| MSL | MSL 1 |
| Customs tariff number | 85361010 |
Compliance
| Property | Value |
|---|---|
| Date of RoHS guidelines | 3/31/15 |
| RoHS conform | Yes |
| SVHC free | Yes |
