3404.0015.11 | SCHURTER
SMD fuse 7.4 x 3.1 mm, 3.5 A, F, 125 V (DC), 125 V (AC), 100 A breaking capacity, 3404.0015.11
Unit Price (€ / pc.)
0.4165 € *
Standard delivery time from the manufacturer is: 8 Weeks
SMD-Fuse, 3404.0015.11, SCHURTER
The 3404.0015.11 is a quick-acting fuse that is designed to protect less sensitive components and are also is used to protect cabling from melting or catching fire when an overload occurs.
Features
- Material housing thermoplastic
- Material terminals copper alloy, tin-plated
- Suitable for reflow and wave soldering
- Vibration resistant
Applications
- Primary protection on SMD PCB-s
Technical specifications
| Filter | Property | Value |
|---|---|---|
| Rated voltage (AC) | 125 V | |
| Length | 7.4 mm | |
| Rated current | 3.5 A | |
| Height | 2.6 mm | |
| Tripping characteristics | F | |
| Width | 3.1 mm | |
| Design | 7.4 x 3.1 mm | |
| Breaking capacity | 100 A | |
| Version | SMD fuse | |
| Enclosure | SMD | |
| Rated voltage (DC) | 125 V |
Download
Logistics
| Property | Value |
|---|---|
| Customs tariff number | 85361010 |
| MSL | MSL 1 |
| Original Packaging | Reel with 100 pieces |
| Country of origin | CH |
Compliance
| Property | Value |
|---|---|
| RoHS conform | Yes |
| SVHC free | Yes |
| Date of RoHS guidelines | 3/31/15 |
