3403.0164.11 | SCHURTER
SMD fuse 3 x 10.1 mm, 630 mA, T, 125 V (DC), 250 V (AC), 200 A breaking capacity, 3403.0164.11
Unit Price (€ / pc.)
0.3808 € *
Standard delivery time from the manufacturer is: 10 Weeks
SMD-Fuse, 3403.0164.11,SCHURTER
The 3403.0164.11 is a time-lag surface mount fuse that allows for a temporary current surge without going above the fuse's current rating. Because of this time delay fuses are most commonly used to protect motor circuits.
Features
- Material ceramic
- Material terminals copper alloy tin-plated
- High breaking capacity
- PCB or SMT mountable
Applications
- Primary protection on SMD PCBs
- Medical equipment
- Battery protection
Technical specifications
| Filter | Property | Value |
|---|---|---|
| Width | 3 mm | |
| Breaking capacity | 200 A | |
| Enclosure | SMD | |
| Rated voltage (DC) | 125 V | |
| Rated voltage (AC) | 250 V | |
| Version | SMD fuse | |
| Tripping characteristics | T | |
| Design | 3 x 10.1 mm | |
| Height | 3 mm | |
| Length | 10.1 mm | |
| Rated current | 630 mA |
Download
Logistics
| Property | Value |
|---|---|
| Original Packaging | Blister with 100 pieces |
| Country of origin | CH |
| Customs tariff number | 85361010 |
Compliance
| Property | Value |
|---|---|
| SVHC free | Yes |
| Date of RoHS guidelines | 3/31/15 |
| RoHS conform | Yes |
