3-140-178 | SCHURTER
SMD fuse 8.4 x 9.4 mm, 100 A, F, 50 V (DC), 2000 A breaking capacity, 3-140-178
Unit Price (€ / pc.)
0.8687 € *
Standard delivery time from the manufacturer is: 19 Weeks
Total Price:
0.87 € *
Price list
Quantity
Price per unit*
1 pcs.
0.8687 €
10 pcs.
0.7854 €
50 pcs.
0.7140 €
100 pcs.
0.6426 €
*incl. VAT plus shipping costs
Subject to prior sale
UHS Fuse, 3-140-178, SCHURTER
This fuse was specially developed for SELV applications with high rated currents for highest breaking capacity demands. Thanks to ist design, the fuses tripping time minimizes excessive temperature dissipation at 2x rated current.
Features
- Safe tripping in 10s at twice the rated current
- High range of operating temperature -55 °C bis 125 °C
- Small component height of 4.7 mm
Applications
- Automotive
- Telecom equipment
- Datacenter appliances
- Power tools
Technical specifications
| Filter | Property | Value |
|---|---|---|
| Tripping characteristics | F | |
| Design | 8.4 x 9.4 mm | |
| Breaking capacity | 2000 A | |
| Version | SMD fuse | |
| Height | 4.7 mm | |
| Rated current | 100 A | |
| Width | 8.4 mm | |
| Length | 9.4 mm | |
| Enclosure | SMD | |
| Rated voltage (DC) | 50 V |
Download
Logistics
| Property | Value |
|---|---|
| Country of origin | CH |
| Customs tariff number | 85361090 |
| Original Packaging | Reel with 1,000 pieces |
Compliance
| Property | Value |
|---|---|
| Date of RoHS guidelines | 3/31/15 |
| RoHS conform | Yes |
| SVHC free | Yes |
