5500.2108 | SCHURTER
AC filter, 50 to 60 Hz, 6 A, 250 VAC, 1.8 mH, PCB connection, 5500.2108
Unit Price (€ / pc.)
37.1518 € *
Standard delivery time from the manufacturer is: 22 Weeks
Total Price:
37.15 € *
Price list
Quantity
Price per unit*
1 pcs.
37.1518 €
10 pcs.
34.5576 €
25 pcs.
32.1419 €
50 pcs.
29.5715 €
*incl. VAT plus shipping costs
Subject to prior sale
1-Phase line filter, 5500.2108, SCHURTER
The 5500.2108 is an AC filter for PCB mounting in flat aluminum housing. This product is designed for use in industrial environments, also has approval from independent testing bodies according to national and international standards.
Features
- Aluminum case provides good shielding
- Protection against interference voltage from the mains
- Universal line filter for standard application
- Suitable for use in equipment
Technical specifications
| Filter | Property | Value |
|---|---|---|
| Connection | PCB connection | |
| Capacity X|Y | X2 100 nF | |
| Number of phases | 1 | |
| max. frequency | 60 Hz | |
| min. frequency | 50 Hz | |
| max. operating temperature | 100 °C | |
| Inductance per line | 1.8 mH | |
| min. operating temperature | -25 °C | |
| Rated Voltage | 250 VAC | |
| Version | AC filter | |
| Rated current | 6 A | |
| With fuse | No | |
| ohmic resistance | 1 MΩ | |
| integrated switch | No |
Download
Logistics
| Property | Value |
|---|---|
| Country of origin | SK |
| Customs tariff number | 85363010 |
| MSL | MSL 1 |
| Original Packaging | Carton with 10 pieces |
Compliance
| Property | Value |
|---|---|
| RoHS conform | Yes |
| SVHC free | Yes |
| Date of RoHS guidelines | 3/31/15 |
