DFKH-22-0003 | SCHURTER
Suppressor choke, radial, 6 mH, 2 A, DFKH-22-0003
Unit Price (€ / pc.)
2.1301 € *
Standard delivery time from the manufacturer is: 16 Weeks
Suppressor inductor, DFKH-22-0003, SCHURTER
The DFKH-22-0003 is a current compensated choke. It is used for limiting currents in electrical lines, for intermediate storage of energy, for impedance matching or for filtering.
Features
- Current compensated choke
- 1-phase choke
- THT-terminals
- Inductor vertically positioned in housing
Applications
- Attenuation of common mode interferences
- Designed for 230/400 VAC applications
- DC drives and stepper motor controls
- Switching power supplies
Technical specifications
| Filter | Property | Value |
|---|---|---|
| Length | 23 mm | |
| DC current | 2 A | |
| Height | 24 mm | |
| Inductance | 6 mH | |
| Width | 13 mm | |
| Design | radial | |
| DC resistance | 150 mΩ | |
| Version | suppressor choke | |
| Tolerance | -30/+50 % |
Download
Logistics
| Property | Value |
|---|---|
| Customs tariff number | 85045000 |
| MSL | MSL 1 |
| Country of origin | LK |
Compliance
| Property | Value |
|---|---|
| RoHS conform | Yes |
| SVHC free | Yes |
| Date of RoHS guidelines | 3/31/15 |
