6160.0075 | SCHURTER

Panel plug C8, 2 pole, snap-in, solder connection, gray, 6160.0075

Order No.: 59P0573
EAN: 4099891584085
MPN:
6160.0075
2578-X-3300-B-420A
Series: 2578
6160.0075 SCHURTER Device Connectors Image 1
6160.0075 SCHURTER Device Connectors Image 2
Image may differ
Unit Price (€ / pc.)
1.4399 € *
Standard delivery time from the manufacturer is: 10 Weeks
Total Price:
1.44 € *
*incl. VAT plus shipping costs
Subject to prior sale
1 pcs.
1.4399 €

Plug C8, 6160.0075, SCHURTER

Snap-in mounting, Front side, Pin temperature 70 °C, Protection class II.

Technical specifications
Filter Property Value
Switch illuminated No
Assembly snap-in
Rated voltage UL/CSA 250 V
Rated current UL/CSA 2.5 A
Panel thickness 20 mm
Pin temperature 70 °C
Fuse holder present No
Design straight
Colour gray
Pin number 2 pole
Rated voltage IEC 250 V
Product type panel plug
Line filter present No
IEC designation C8
Rated current IEC 2.5 A
Type of locking No
Connection solder connection
Power switch available No
Logistics
Property Value
Original Packaging Carton with 100 pieces
Customs tariff number 85366990
Country of origin DE
Compliance
Property Value
RoHS conform Yes
Date of RoHS guidelines 3/31/15
SVHC free Yes
