3-127-468 | SCHURTER
Combination element C14, 2 pole, Snap-in mounting, plug-in connection, black, 3-127-468
Order No.: 59P0151
EAN: 4099891581886
MPN:
3-127-468
6135-CBDBF100C0-000-C6135-4412-100
Series: 6135
Unit Price (€ / pc.)
19.6231 € *
Available: 0 pcs.
Leadtime: 10 Weeks **
IEC plug C14, 3-127-468, SCHURTER
Features
- Unwired
- Snap-in version front side
- Protection class I
- Circuit breaker type TA35
Applications
- Suitable for use in equipment
- Suitable for appliances with protection class I
Technical specifications
| Connection | Steckanschluss | |
| Version | Kombielement | |
| Design | gerade | |
| Swich colour | schwarz | |
| Colour | schwarz | |
| IEC designation | C14 | |
| Assembly | Schnappmontage | |
| Rated voltage IEC | 250 V | |
| Rated voltage UL/CSA | 250 V | |
| Rated current IEC | 10 A | |
| Rated current UL/CSA | 15 A | |
| Line filter present | No | |
| Switch illuminated | No | |
| Power switch available | Yes | |
| Panel thickness | 1.5 mm | |
| Number of poles switch | 2-polig | |
| Pin number | 2-polig | |
| Fuse holder present | No | |
| Pin temperature | 70 °C | |
| Type of locking | Ja |
Download
Compliance
| RoHS conform | Yes |
| Date of RoHS guidelines | 3/31/15 |
| SVHC free | Yes |
