3-100-202 | SCHURTER

Panel plug C8, 2 pole, snap-in, PCB connection, black, 3-100-202

Order No.: 59P0679
EAN: 4099891584979
MPN:
3-100-202
2578-X-AA00-A-420A
Series: 2578
3-100-202 SCHURTER Device Connectors
Image may differ
Unit Price (€ / pc.)
1.4994 € *
Standard delivery time from the manufacturer is: 10 Weeks
Total Price:
1.50 € *
*incl. VAT plus shipping costs
Subject to prior sale
1 pcs.
1.4994 €

Plug, 3-100-202, SCHURTER

Features

  • Contact pins are turned from solid material
  • Pin temperature 70 °C
  • Protection class II

Applications

  • Suitable for appliances with protection class II
Technical specifications
Filter Property Value
IEC designation C8
Pin number 2 pole
Colour black
Rated voltage IEC 250 V
Assembly snap-in
Type of locking No
Fuse holder present No
Rated voltage UL/CSA 125 V
Rated current UL/CSA 7 A
Power switch available No
Line filter present No
Rated current IEC 2.5 A
Design straight
Connection PCB connection
Panel thickness 2 mm
Switch illuminated No
Product type panel plug
Pin temperature 70 °C
Logistics
Property Value
Customs tariff number 85366990
Original Packaging Carton with 100 pieces
Country of origin DE
Compliance
Property Value
Date of RoHS guidelines 3/31/15
SVHC free Yes
RoHS conform Yes
