4411.0230 | SCHURTER

Circuit breaker, 1 pole, T characteristic, 200 mA, 28 V (DC), 240 V (AC), faston plug 6.3 x 0.8 mm, snap-in, IP40, 4411.0230

Order No.: 59P6664
EAN: 4099889141887
MPN:
4411.0230
T13-671R-0.2
Series: T13-671
4411.0230 SCHURTER Device Circuit Breakers
Image may differ

As a private customer, you can buy this item as soon as we have it back in stock.

Device circuit breaker, 4411.0230, SCHURTER

The 4411.0230 is a thermal circuit breaker for equipment (CBE) and is particularly suitable for protection of motors and transformers against current overload.

Features

  • Wide current range
  • High breaking capacity
  • Compact design
  • Positively trip-free release
  • Different mounting possibilities
  • High dielectric strength

Applications

  • Power supplies
  • Uninterruptible power supply
  • Power tools
  • Household appliances
Technical specifications
Rated voltage (DC) 28 V
Actuator push button
Degree of protection (IP) IP40
Type of mounting snap-in
Rated current 200 mA
Tripping characteristics T
Product type circuit breaker
Rated voltage (AC) 240 V
Pin number 1 pole
Connection faston plug 6.3 x 0.8 mm
Logistics
Country of origin CZ
Customs tariff number 85362010
MSL MSL 1
Original Packaging Carton with 20 pieces
Compliance
Date of RoHS guidelines 3/31/15
SVHC free Yes
RoHS conform Yes
