4410.9006 | SCHURTER
Circuit breaker, 1 pole, T characteristic, 16 A, 28 V (DC), 240 V (AC), faston plug 6.3 x 0.8 mm, panel mounting, IK07, 4410.9006
Unit Price (€ / pc.)
37.2708 € *
Standard delivery time from the manufacturer is: 8 Weeks
Thermal circuit breaker, 4410.9006, SCHURTER
The 4410.9006 is a thermal-magnetic circuit breaker for equipment and it is a threaded neck type with a manual switch button.
Features
- Compact design
- Positively trip-free release
- Different mounting possibilities
- High dielectric strength
Applications
- Power tools
- Household equipment
- Power supplies and chargers
- Industrial appliances
Technical specifications
| Filter | Property | Value |
|---|---|---|
| Rated voltage (DC) | 28 V | |
| Type of mounting | panel mounting | |
| Connection | faston plug 6.3 x 0.8 mm | |
| Degree of protection (IP) | IK07 | |
| Rated voltage (AC) | 240 V | |
| Tripping characteristics | T | |
| Actuator | push button | |
| Product type | circuit breaker | |
| Pin number | 1 pole | |
| Rated current | 16 A |
Download
Logistics
| Property | Value |
|---|---|
| Customs tariff number | 85362010 |
| Country of origin | CZ |
| MSL | MSL 1 |
| Original Packaging | Carton with 10 pieces |
Compliance
| Property | Value |
|---|---|
| RoHS conform | Yes |
| SVHC free | Yes |
| Date of RoHS guidelines | 3/31/15 |
