FK 02 L NI / GN | SCHÜTZINGER
2 mm plug, solder connection, 0.5 mm², green, FK 02 L NI / GN
Unit Price (€ / pc.)
1.1662 € *
Available: 20 pcs.
Total Price:
1.17 € *
Price list
Quantity
Price per unit*
1 pcs.
1.1662 €
20 pcs.
1.0829 €
60 pcs.
0.9996 €
100 pcs.
0.9401 €
500 pcs.
0.8806 €
*incl. VAT plus shipping costs
Subject to prior sale
Laboratory connector, FK 02 L NI / GN, SCHÜTZINGE
The FK 02 L NI / GN is a spring plug or a lamella plug, is a connector designed primarily for electrical laboratories for low voltage at low to medium electrical current.
Features
- Press-in
- Low rated current
- Low rated voltage
- Crimp connection
Technical specifications
| Filter | Property | Value |
|---|---|---|
| Version | plug | |
| contact surface | nickel-plated | |
| Rated Voltage | 30 VAC/60 VDC | |
| Rated current | 10 A | |
| Touch safe | No | |
| Cable cross-section | 0.5 mm² | |
| diameter | 2 mm | |
| Length | 32 mm | |
| Connection | solder connection | |
| Colour | green |
Download
Compliance
| Property | Value |
|---|---|
| Date of RoHS guidelines | 3/31/15 |
| RoHS conform | Yes |
| Substance description | Lead |
| SVHC free | No |
