RE22R1MLMR | Schneider Electric
Flasher relay, 0.05 s to 300 h, blinking, 1 Form C (NO/NC), 24-240 V AC/DC, 8 A/250 VAC, RE22R1MLMR
Unit Price (€ / pc.)
75.684 € *
Available in 3 Days: 15 pcs. - if ordered today
Flasher relay, RE22R1MLMR, Schneider Electric
This Harmony RE22 modular dual function timer can be set between 1 seconds and 300 hours, has an output rating of 8 amperes and it is 22.5 millimeters wide. This modular dual function timing relay is ideal for providing timing control in automation systems such as automatic door opening, alarm, lighting in toilets and car park barriers. It is also ideal for refurbishment of old installations without using a PLC.
Technical specifications
| Filter | Property | Value |
|---|---|---|
| Time display | 0.05 s to 300 h | |
| Function | blinking | |
| Contact type | 1 Form C (NO/NC) | |
| Voltage | 24-240 V AC/DC | |
| Breaking capacity | 8 A/250 VAC | |
| Connection | screw connection |
Download
Logistics
| Property | Value |
|---|---|
| Customs tariff number | 85364900 |
| Country of origin | ID |
Compliance
| Property | Value |
|---|---|
| RoHS conform | Yes |
| SVHC free | No |
| Substance description | 1, 2-dimethoxyethane; ethylene glycol dimethyl ether (EGDME) |
| Date of RoHS guidelines | 3/31/15 |
| Sustainable | Yes |
