VZ4 | Schneider Electric
Main contact module, 1 pole, 80 A, 690 VAC, (L x W x H) 46 x 20 x 83 mm, for V4, VZ4
Unit Price (€ / pc.)
20.1348 € *
Standard delivery time from the manufacturer is: 1 Week
Main contact module, VZ4, Schneider Electric
TeSys Vario add-on module, main pole 80A 690V, for Vario switch-disconnectors. To be used with V4 switch bodies. A maximum of 3 additional VZ4 modules can be attached to the switch body. Multi standards certified (IEC, UL, CSA, CCC, EAC), Green Premium compliant (RoHS/REACh).
Technical specifications
| Filter | Property | Value |
|---|---|---|
| Height | 83 mm | |
| Version | 1 pole, 80 A, 690 VAC | |
| Width | 20 mm | |
| Suitable for | V4 | |
| Length | 46 mm | |
| Product type | main contact module |
Download
Logistics
| Property | Value |
|---|---|
| Customs tariff number | 85389099 |
| Country of origin | CZ |
Compliance
| Property | Value |
|---|---|
| RoHS conform | Yes |
| Sustainable | Yes |
| Substance description | Lead |
| SVHC free | No |
| Date of RoHS guidelines | 3/31/15 |
