VCFXGE1 | Schneider Electric
Empty enclosure, (L x W x H) 131 x 90 x 146 mm, red/yellow, for VN12-VN20/V02-V2, VCFXGE1
Unit Price (€ / pc.)
30.0356 € *
Standard delivery time from the manufacturer is: 2 Weeks
Enclosure, VCFXGE1, Schneider Electric
TeSys enclosed starters, empty enclosure for mounting a switch disconnector for main switching in motor applications up to 15kW@400V AC-23. Enclosure providing IP65 protection, fitted with a red rotary handle and yellow front plate, padlockable (padlocks not included). to be equipped with a Vario switch body VN12-VN20 or V02-V2 (to be ordered separately), with 2 possible add-on module attachments Surface mounting enclosure with screw fixing, 2 knock-outs for cable glands on top and bottom, sealable cover.
Technical specifications
| Filter | Property | Value |
|---|---|---|
| Length | 131 mm | |
| Product type | empty enclosure | |
| Height | 146 mm | |
| Width | 90 mm | |
| Suitable for | VN12-VN20/V02-V2 | |
| Colour | red/yellow |
Download
Logistics
| Property | Value |
|---|---|
| Country of origin | CZ |
| Customs tariff number | 85381000 |
Compliance
| Property | Value |
|---|---|
| Date of RoHS guidelines | 3/31/15 |
| Sustainable | Yes |
| Substance description | Lead |
| RoHS conform | Yes |
| SVHC free | No |
