19067 | Schneider Electric
Undervoltage release, 230-240 VAC, (L x W x H) 78 x 32 x 113 mm, for circuit breaker, 19067
Order No.: 01P2753
EAN: 3303430190677
MPN:
19067
NCNR (non cancelable / non returnable)
Unit Price (€ / pc.)
124.3431 € *
Standard delivery time from the manufacturer is: 1 Week
Undervoltage releases, 19067, Schneider Electric
This Acti9 MN electrical auxiliary is a undervoltage release device. It is dedicated to NG125. It prevents device closing again until its input voltage has been restored. The width in 9mm pitches is 4. The product trips the associated device when it is powered on. The Uc control circuit voltage is 230…240 VAC. It can be mounted on a DIN rail for modular installation. The operating temperature is - 25°C to 60°C. The storage temperature is - 40°C to 85°C. This product complies with IEC/EN 60947 - 5 - 1 standards.
Technical specifications
| Filter | Property | Value |
|---|---|---|
| Product type | undervoltage release | |
| Version | 230-240 VAC | |
| Length | 78 mm | |
| Width | 32 mm | |
| Height | 113 mm | |
| Suitable for | circuit breaker |
Download
Logistics
| Property | Value |
|---|---|
| Customs tariff number | 85365080 |
| Country of origin | BE |
Compliance
| Property | Value |
|---|---|
| Date of RoHS guidelines | 3/31/15 |
| RoHS conform | Yes |
| SVHC free | Yes |
