SSL1D101BD | Schneider Electric
Solid state relay, 16-30 VDC, DC switching, 1-48 VDC, 0.1 A, PCB mounting, SSL1D101BD
Unit Price (€ / pc.)
12.7330 € *
Available: 0 pcs.
Leadtime: 13 Weeks **
Solid state relay, SSL1D101BD, Schneider Electric
This Zelio SSL slim interfacing solid state plug-in relay is rated 0.1A, is controlled with a 16V to 30V DC input, has a rated load voltage of 1V to 48V DC with DC switching. It is 6mm width, including socket, to save space in your control cabinets. It is also silent and reliable thanks to the absence of moving contacts. It is shock, vibration and pollution resistant thanks to its IP67, it makes it ideal for harsh industrial environments.
Technical specifications
| LED display | No | |
| Assembly | PCB mounting | |
| Rated current | 0.1 A | |
| Switching Mode | DC switching | |
| Voltage | 1-48 VDC | |
| Control Voltage | 16-30 VDC |
Download
Logistics
| Country of origin | MX |
| Customs tariff number | 85364900 |
Compliance
| RoHS conform | Yes |
| Date of RoHS guidelines | 3/31/15 |
| SVHC free | Yes |
| Sustainable | Yes |
