ABS7EC3B2 | Schneider Electric

Solid state relay, 24 VDC, 5-24 VAC, plug-in connection, ABS7EC3B2

Order No.: 01P8869
EAN: 4099889356526
MPN:
ABS7EC3B2
ABS7EC3B2 Schneider Electric Solid State Relays
Image may differ
Unit Price (€ / pc.)
33.2962 € *
Standard delivery time from the manufacturer is: 1 Week
Total Price:
33.30 € *
Price list
Quantity
Price per unit*
1 pcs.
33.2962 €
2 pcs.
31.9634 €
4 pcs.
30.7377 €
*incl. VAT plus shipping costs
Subject to prior sale

Relay, ABS7EC3B2, Schneider Electric

This product is part of the Modicon ABE7 range, an offer of connection sub-bases for Telefast pre-wired system. This plug-in solid state relay is compatible with Modicon ABE7 connection sub-bases. It is a solid state input relay with a discrete input voltage of 24 V DC. The response time is ≤0.05 ms from state 0 to 1 and ≤0.4 ms from state 1 to 0. The width pitch is 12 mm. It weighs 0.014 kg. It is suitable for all types of industrial applications. This product is suitable for use with Modicon ABE7P16F310, ABE7P16F310E and ABE7P16F312 sub-base. Modicon ABE7 means greater simplicity to rationalise wiring in your automation system equipment. Pre-wired system enabling connection and adaptation of control signals of PLC cards equipped with HE10 connectors.

Technical specifications
LED display No
Assembly plug-in connection
Control Voltage 24 VDC
Voltage 5-24 VAC
Logistics
Country of origin LV
Customs tariff number 85364190
Compliance
Date of RoHS guidelines 3/31/15
Substance description Cadmium, lead
SVHC free No
RoHS conform Yes
Sustainable Yes
