LA4DC3U | Schneider Electric
Function module, diodes, 24-250 VDC for LC1D80/D95, LA4DC3U
NCNR (non cancelable / non returnable)
Unit Price (€ / pc.)
14.7441 € *
Available in 3 Days: 1 pcs. - if ordered today
Suppressor module, LA4DC3U, Schneider Electric
TeSys D suppressor module, for LC1D80-D95 (3P), LP1D40-D80 (4P) contactors. To be used with 24V-250V DC control circuit voltage, it provides flywheel diode protection ensuring no transient overvoltage. Mounting on top of contactor, screw fixing and connection on coil terminals (polarized component). Green Premium compliant (RoHS/REACh).
Technical specifications
| Filter | Property | Value |
|---|---|---|
| Product type | function module | |
| Version | diodes, 24-250 VDC | |
| Suitable for | LC1D80/D95 |
Download
Logistics
| Property | Value |
|---|---|
| Country of origin | FR |
| Customs tariff number | 85389099 |
Compliance
| Property | Value |
|---|---|
| Sustainable | Yes |
| RoHS conform | Yes |
| Date of RoHS guidelines | 3/31/15 |
| SVHC free | Yes |
