GV4L02N | Schneider Electric
Motor protection switch, 3 pole, 1 kW, 2 A, screw connection, GV4L02N
Unit Price (€ / pc.)
330.3321 € *
Standard delivery time from the manufacturer is: 4 Weeks
Motor circuit breaker, GV4L02N, Schneider Electric
TeSys GV motor circuit breaker, 3 poles (3P), 2A/690V, for protection of 3-phase motors 0.25-0.75kW@400V. It provides magnetic protection, breaking capacity Icu 50kA@400V, start-stop control by rotary handle, connection by Everlink BTR screw terminals. Magnetic protection adjustable by dial, setting range 6-14 In. It makes internal locations available for additional auxiliary contact blocks (OF, SD), and voltage trip units (MN, MX). To be used in association with a class 10 or 20 thermal overload relay to complete motor protection. Multi standards certified (IEC, CCC, EAC, Marine), Green Premium compliant (RoHS/REACh).
Technical specifications
| rated voltage (AC) | 690 V | |
| Actuator | rotary knob | |
| Degree of protection (IP) | IP40 | |
| Assembly | DIN rail | |
| Rated current | 2 A | |
| Network frequency | 50/60 Hz | |
| Engine power | 1 kW | |
| Pin number | 3 pole | |
| Version | motor protection switch | |
| Connection | screw connection |
Download
Logistics
| Country of origin | PL |
| Customs tariff number | 85369010 |
Compliance
| Date of RoHS guidelines | 3/31/15 |
| Substance description | Lead |
| SVHC free | No |
| RoHS conform | Yes |
| Sustainable | Yes |
