CCT5015-0002W | Schneider Electric
Blind control, dark gray, 240 V (AC), 4 A, IP20, CCT5015-0002W
Unit Price (€ / pc.)
80.3131 € *
Standard delivery time from the manufacturer is: 1 Week
Total Price:
80.31 € *
Price list
Quantity
Price per unit*
1 pcs.
80.3131 €
3 pcs.
76.8264 €
5 pcs.
73.6372 €
*incl. VAT plus shipping costs
Subject to prior sale
Connected shutter control, CCT5015-0002W, Schneider Electric
Wiser flush-mounted shutter actuator controls a shutter/blind motor with limit switch in a Wiser home automation system (Zigbee). Mechanically and electronically interlocked relay contacts. Up to 64 devices including hub can be connected via one system. Modular smart home connection via the Wiser system, APP control on site and remotely, schedules, moments (scenes) and automations via Wiser Home APP. Zigbee 3.0 (factory setting) and Bluetooth. 1 blind channel. Neutral conductor required, screw terminal connection.
Technical specifications
| Filter | Property | Value |
|---|---|---|
| Degree of protection (IP) | IP20 | |
| Product type | blind control | |
| illuminated | Yes | |
| Rated voltage (AC) | 240 V | |
| Colour | dark gray | |
| Rated current | 4 A |
Download
Logistics
| Property | Value |
|---|---|
| Country of origin | CN |
| Customs tariff number | 85371098 |
Compliance
| Property | Value |
|---|---|
| Date of RoHS guidelines | 3/31/15 |
| SVHC free | No |
| Substance description | Lead, boron trioxide |
| RoHS conform | Yes |
