9080GCB20 | Schneider Electric
Circuit breaker, thermal-magnetic, 1 pole, C characteristic, 2 A, 65 V (DC), 250 V (AC), DIN rail, 9080GCB20
Unit Price (€ / pc.)
98.1036 € *
Standard delivery time from the manufacturer is: 4 Weeks
Device circuit breaker, 9080GCB20, SCHNEIDER
The 9080GCB20 is a thermal magnetic circuit protection device with trip-free operation. The thermal feature trips when there is an overload of ten times rated current or less. The magnetic mechanism trips instantaneously when there is a short circuit.
Features
- DIN rail mounting
- RoHS compatible
Applications
- Industrial application
Technical specifications
| Filter | Property | Value |
|---|---|---|
| Rated voltage (AC) | 250 V | |
| Rated current | 2 A | |
| Tripping characteristics | C | |
| Type of mounting | DIN rail | |
| Actuator | push button | |
| Product type | circuit breaker | |
| Pin number | 1 pole | |
| Version | thermal-magnetic | |
| Rated voltage (DC) | 65 V |
Download
Logistics
| Property | Value |
|---|---|
| Customs tariff number | 85365080 |
| Country of origin | DE |
Compliance
| Property | Value |
|---|---|
| RoHS conform | Yes |
| SVHC free | Yes |
| Date of RoHS guidelines | 3/31/15 |
| Sustainable | Yes |
