LA1KN043 | Schneider Electric

Auxiliary switch block, 4 pole, 10 A, 690 V, 4 Form B (N/C), coil 690 VAC, LA1KN043

Order No.: 03P0533
EAN: 4099889419887
MPN:
LA1KN043
Series: TeSys K
LA1KN043 Schneider Electric Contactors
Image may differ
Unit Price (€ / pc.)
23.4906 € *
Standard delivery time from the manufacturer is: 1 Week
Total Price:
23.49 € *
*incl. VAT plus shipping costs
Subject to prior sale
1 pcs.
23.4906 €

Auxiliary switch block, LA1KN043, Schneider Electric

TeSys K instantaneous auxiliary contact block, for contactors LC.K, LP.K, CA.K with screw clamp terminals (except LP4K, LP5K, CA4K). It provides 4NC contacts rated up to 10A 690V AC, connection by spring terminals. Front mounting by clip-on, it procures high reliability and durability. Multi standards certified (IEC, UL, CSA, CCC), Green Premium compliant (RoHS/REACh).

Technical specifications
Degree of protection (IP) IP20
Assembly front mounting
Rated current 10 A
Control Voltage 690 VAC
Pin number 4 pole
Version auxiliary switch block
Rated Voltage 690 V
Latching switching function 4 Form B (N/C)
Logistics
Country of origin FR
Customs tariff number 85365080
Compliance
Date of RoHS guidelines 3/31/15
SVHC free Yes
RoHS conform Yes
Sustainable Yes
