A9N61650 | Schneider Electric

Circuit breaker, 2 pole, B Curve, 10 A, 800 V, DIN rail, A9N61650

Order No.: 01P8271
EAN: 4099889150698
MPN:
A9N61650
Series: Acti 9
A9N61650 Schneider Electric Circuit Protectors
Image may differ
Unit Price (€ / pc.)
110.0036 € *
Standard delivery time from the manufacturer is: 1 Week
Total Price:
110.00 € *
*incl. VAT plus shipping costs
Subject to prior sale
1 pcs.
110.0036 €

Circuit breaker, A9N61650, SCHNEIDER

The A9N61650 is a low voltage miniature circuit breaker dedicated to multi string photovoltaic installations. It is a 2P circuit breaker with 2 protected poles and 10 A In rated current and B tripping curve. The rated short circuit breaking capacity goes up to 1.5 kA at 800 V DC. This miniature circuit breaker protects circuits against short circuit and overload current.

Features

  • High breaking capacity
  • High rated impulse withstand voltage
  • High mechanical durability
  • High electrical durability
Technical specifications
Rated voltage (DC) 800 V
Degree of protection (IP) IP40
Assembly DIN rail
Tripping characteristics B
Product type circuit breaker
Pin number 2 pole
Rated Voltage 800 V
Rated current 10 A
Logistics
Country of origin CN
Customs tariff number 85362010
Compliance
Date of RoHS guidelines 3/31/15
SVHC free Yes
RoHS conform Yes
Sustainable Yes
