A9N18391 | Schneider Electric

Circuit breaker, 4 pole, D Curve, 80 A, 400 V, DIN rail, A9N18391

Order No.: 01P8079
EAN: 3606480379628
MPN:
A9N18391
Series: C120
A9N18391 Schneider Electric Circuit Protectors
Image may differ
Unit Price (€ / pc.)
414.5008 € *
Available in 3 Days: 6 pcs. - if ordered today
Total Price:
414.50 € *
*incl. VAT plus shipping costs
Subject to prior sale
1 pcs.
414.5008 €

Circuit breaker, A9N18391, SCHNEIDER

The A9N18391 is a multistandard low voltage miniature circuit breaker. It is a 4P circuit breaker with 4 protected poles and 80 A In rated current and D tripping curve. The rated short circuit breaking capacity goes up to 10000 A at 230 V AC 400 V AC. This miniature circuit breaker protects circuits against short circuit and overload current.

Features

  • High breaking capacity
  • High rated impulse withstand voltage
  • High mechanical durability
  • High electrical durability
Technical specifications
Filter Property Value
Rated voltage (DC) 500 V
Product type circuit breaker
Pin number 4 pole
Rated voltage (AC) 440 V
Tripping characteristics D
Rated Voltage 400 V
Rated current 80 A
Degree of protection (IP) IP20
Assembly DIN rail
Logistics
Property Value
Country of origin FR
Customs tariff number 85362090
Compliance
Property Value
RoHS conform Yes
Sustainable Yes
Date of RoHS guidelines 3/31/15
SVHC free Yes
