NHGF36060U31XTW | Schneider Electric
Circuit breaker, toggle actuator, 3 pole, 60 A, 750 V, (W x H x D) 104 x 163 x 86 mm, DIN rail, NHGF36060U31XTW
Unit Price (€ / pc.)
805.4872 € *
Standard delivery time from the manufacturer is: 2 Weeks
Circuit breaker, NHGF36060U31XTW, Schneider Electric
This PowerPact Multistandard H-frame moulded-case circuit-breaker has 3 poles, is ready for installation and has a rated line current of 60 A at 40 °C. It is equipped with an electronic Micrologic 3.0 trip unit that provides LI protection and has a breaking capacity of 18 kA at 600V AC in accordance with UL 489 and 18 kA at 500/525V AC in accordance with IEC 947-2. This circuit breaker has an over-centre, trip-free toggle mechanism with fast tripping. The handle of the circuit breaker can be set to one of three positions: ON, tripped or OFF, with a positive visual indication when the circuit breaker has tripped and the circuit has been interrupted.
Technical specifications
| Filter | Property | Value |
|---|---|---|
| Pin number | 3 pole | |
| Actuator | toggle actuator | |
| Height | 163 mm | |
| Degree of protection (IP) | IP40 | |
| Assembly | DIN rail | |
| Depth | 86 mm | |
| Width | 104 mm | |
| Permanent current | 60 A | |
| Isolation voltage | 750 V | |
| Product type | circuit breaker |
Download
Logistics
| Property | Value |
|---|---|
| Customs tariff number | 85362090 |
| Country of origin | US |
Compliance
| Property | Value |
|---|---|
| RoHS conform | Yes |
| Sustainable | Yes |
| Substance description | Lead |
| SVHC free | No |
| Date of RoHS guidelines | 3/31/15 |
