GB2CB14 | Schneider Electric
Circuit breaker, toggle actuator, 1 pole, 8 A, (W x H x D) 15 x 74 x 67 mm, mounting plate, GB2CB14
Unit Price (€ / pc.)
21.6104 € *
Available in 3 Days: 4 pcs. - if ordered today
Circuit breaker, GB2CB14, Schneider Electric
TeSys GB circuit breaker, 1 pole (1P), 8 A/250 V IEC/277V UL, for the protection of industrial equipment control circuits. It provides thermal-magnetic protection with a magnetic tripping level at 108 A (13 In) and breaking capacity Icu 1.5 kA@240 V. It can also be used for protection of DC loads up to 8 A/48V DC-13 with a breaking capacity Icu 1.5 kA@24 V. Compact device (15 mm wide), mounting on 35 mm DIN-rail, control by toggle lever (start-stop guaranteed for 8000 cycles). Sold in lots of 6 units. Multi standards certified (IEC, UL, CSA), Green Premium product (RoHS/REACh).
Technical specifications
| Filter | Property | Value |
|---|---|---|
| Product type | circuit breaker | |
| Pin number | 1 pole | |
| Actuator | toggle actuator | |
| Assembly | mounting plate | |
| Width | 15 mm | |
| Height | 74 mm | |
| Depth | 67 mm | |
| Permanent current | 8 A | |
| Degree of protection (IP) | IP20 |
Download
Logistics
| Property | Value |
|---|---|
| Customs tariff number | 85362010 |
| Country of origin | FR |
Compliance
| Property | Value |
|---|---|
| RoHS conform | Yes |
| SVHC free | Yes |
| Sustainable | Yes |
| Date of RoHS guidelines | 3/31/15 |
