18894 | Schneider Electric
Load-break switch, toggle actuator, 4 pole, 80 A, 690 V, (W x H x D) 108 x 103 x 81 mm, DIN rail, 18894
Order No.: 01P2717
EAN: 3303430188940
MPN:
18894
Unit Price (€ / pc.)
280.8519 € *
Standard delivery time from the manufacturer is: 1 Week
Switch-disconnector, 18894, Schneider Electric
Acti 9 NG125LMA circuit-breaker, 50 kA (IEC/EN 60947-2). 3-pole, rated current 25 A, MA characteristic, operating voltage (Ue) 380-415V AC, insulation voltage (Ui) 690V AC. Circuit protection against short-circuit currents. Protection of the circuit against overload currents. Tripping is indicated by the centre position of the switching toggle and by a red mechanical indicator on the front of the device.
Technical specifications
| Filter | Property | Value |
|---|---|---|
| Isolation voltage | 690 V | |
| Depth | 81 mm | |
| Height | 103 mm | |
| Assembly | DIN rail | |
| Width | 108 mm | |
| Permanent current | 80 A | |
| Degree of protection (IP) | IP20 | |
| Actuator | toggle actuator | |
| Product type | load-break switch | |
| Pin number | 4 pole |
Download
Logistics
| Property | Value |
|---|---|
| Customs tariff number | 85362090 |
| Country of origin | FR |
Compliance
| Property | Value |
|---|---|
| RoHS conform | Yes |
| SVHC free | Yes |
| Date of RoHS guidelines | 3/31/15 |
