18890 | Schneider Electric
Load-break switch, toggle actuator, 3 pole, 80 A, 690 V, (W x H x D) 81 x 103 x 81 mm, DIN rail, 18890
Order No.: 01P2713
EAN: 3303430188902
MPN:
18890
Unit Price (€ / pc.)
192.9585 € *
Standard delivery time from the manufacturer is: 1 Week
Switch-disconnector, 18890, Schneider Electric
This Acti9 product is a NG125A 3P switch disconnector. It is fixed on DIN rail. The Ie rated operational current is 80A with a Ue rated operational voltage of 500 VAC with a 50/60 Hz frequency.
Technical specifications
| Filter | Property | Value |
|---|---|---|
| Isolation voltage | 690 V | |
| Depth | 81 mm | |
| Height | 103 mm | |
| Assembly | DIN rail | |
| Width | 81 mm | |
| Permanent current | 80 A | |
| Degree of protection (IP) | IP20 | |
| Actuator | toggle actuator | |
| Product type | load-break switch | |
| Pin number | 3 pole |
Download
Logistics
| Property | Value |
|---|---|
| Customs tariff number | 85362090 |
| Country of origin | FR |
Compliance
| Property | Value |
|---|---|
| RoHS conform | Yes |
| SVHC free | Yes |
| Date of RoHS guidelines | 3/31/15 |
